NEO digital protractor

The NEO Tools Digital Angle Gauge (72-300) provides accurate angle measurements for various applications, such as setting cutting angles, automotive testing, and household chores. With a clear LCD screen, base with magnet for easy mounting, and useful functions such as REF (zero reference value) and HOLD (save measurement results). With a high measuring resolution of 0.01° and the ability to measure in degrees, slope in %, mm/m, and in/ft. A handy and versatile tool for precision work with automatic switch-off after 3 minutes of non-use. Power supply with 2x 1.5V AAA batteries for portable use.

• LCD Display
• Base with magnet
• High measuring resolution of 0.01°
• Measurement in 4 units: degrees, slope in %, mm/m, in/ft
• Automatic shutdown after 3 minutes of non-use
• Power supply: 2x 1.5V AAA
• REF function: zero setting at any position (reference measurement)
• HOLD function: save the measurement result

Technical data:

• Measuring range: 4÷90°?
• Digital measurement resolution: ±0.01°?
• Digital measurement accuracy: ±0.1° for 0° and 90° and ±0.2° for other angles
• Units of measurement: (°degrees / % / mm/m / IN/FT)?
• ABS housing

Article number: 18939-E
